1/2HP LEESON 3410RPM D71D IP55 3PH IEC MOTOR 192034

Catalog Number:  192034.00
Model Number: C71T34FZ5
Description:  1/2HP,3410RPM,D71D,IP55,3PH,60/50HZ,IEC METRIC
Ship Weight:  13 lbs.

LEESON IEC Metric-dimensioned AC motors meeting North American performance standards, including 1.15 service factor and EPACT efficiencies. Motors have both B5 flange mounting and B3 base

  • Aluminum Frame
  • Removable feet.
  • Drain Hole locations in four quadrants can be drilled-out for multi-position condensate drainage.
  • D flange (B5) and rigid base (B3) mounting
  • “Captive Shaft” keyway.
  • Drilled and tapped shaft.
  • Oil Seals on both the drive end and non drive end.
  • High efficiency design utilizes low-loss steel laminations for optimum power and performance.
  • Class F insulation system with Class B temperature rise or lower.
  • Aluminum “full fact” nameplate with information on motor efficiency and power factor. Stamped
    with 60Hz and 50Hz data.
  • Multi-mount repositionable feet allow for three conduit box positions (F2, F1, F3)
  • External grounding provision.
  • Special design steel fan cover and low-noise fan maximize airflow efficiency.
  • Conduit Box with neoprene gaskets. Reposition metric “PG” tapped lead exit hole by rotating box
    in 90 degree increments. Move box to F1 or F2 position by relocating motor feet.
  • Terminal Boards included. 230/460V motors have 9 leads.
  • CSA: File number LR33543
    UL: File number E57948 for motors produced January 2004 and later
  • IP55 weatherproof enclosure allows for use in wide range application.
Volts 230 Volts 460 Volts 200/400
F.L. Amps 1.6 F.L. Amps .8 F.L. Amps 1.9/.95
S. F Amps 1.8 S. F Amps .90 S. F Amps 2.2/1.1
RPM 3600 Hertz 60/50
KW .373 Model # C71T34FZ5C
Frame D71D Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code J
Insul Class F Protection NOT Therm.Prot.
Eff 100% 74 Eff 75%   PF 79
UL Yes CSA Yes Bearing OPE 6203
CC Number NONE CE Yes Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NAN
Motor Wt. 13 LB Enclosure IP55 Lubrication STANDARD
Nameplate 081044 Mounting B3/B5 Rotation REV
1/2HP LEESON 3410RPM D71D IP55 3PH IEC MOTOR 192034
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 192034.00
Stock # 192034
Price: $214.00
Compare At: $419.00
