1/4HP LEESON 1700RPM D63 IP55 3PH IEC MOTOR 192011

Catalog Number:  192011.00
Model Number: C63T17FZ1C
Description:  1/4HP,1700RPM,D63,IP55,3PH,60/50HZ,IEC METRIC
Ship Weight:  12 lbs.

LEESON AC METRIC MOTORS meet international standards and feature IP55 weatherproof enclosures, 60/50Hz interchangeability (60Hz 230/460 V & 50Hz 200/400V) dual stamped nameplates, CE mark, and F3 conduit box location.

  • Aluminum Frame
  • Removable feet
  • Drain Hole locations in four quadrants can be drilled-out for multi-position condensate drainage.
  • D flange (B5) and C face (B14) models available. Field conversion kits also offered.
  • “Captive Shaft” keyway.
  • Drilled and tapped shaft.
  • Oil Seals on both the drive end and non drive end.
  • High efficiency design utilizes low-loss steel laminations for optimum power and performance.
  • Class F insulation system with Class B temperature rise or lower.
  • Aluminum “full fact” nameplate with information on motor efficiency and power factor. Stamped
    with 60Hz and 50Hz data.
  • Multi-mount repositionable feet allow for three conduit box positions (F2, F1, F3)
  • External grounding provision.
  • Special design steel fan cover and low-noise fan maximize airflow efficiency.
  • Conduit Box with neoprene gaskets. Reposition metric “PG” tapped lead exit hole by rotating box
    in 90 degree increments. Move box to F1 or F2 position by relocating motor feet.
  • Terminal Boards included. 230/460V motors have 9 leads.
  • CSA: File number LR33543
    UL: File number E57948 for motors produced January 2004 and later
  • IP55 weatherproof enclosure allows for use in wide range application.
Volts 230   Volts 460   Volts 200/400
FL Amps 1.0   FL Amps 0.5   FL Amps 1.2/0.6
SF Amps 1.1   SF Amps .57   SF Amps 1.4/0.7
RPM 1800   Hertz 60/50
HP 1/4   Duty CONTINUOUS   Type TF
KW .187   SF 1.15   Phase 3
Frame D63   Design B   KVA Code H
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class F   Eff(75%)     PF 62.5
Eff(100%) 68   CSA Y   Bearing OPE 6202
UL Y   CE Y   Bearing PE 6202
CC Number     Inverter Type     Speed Range 1.5 X BASE SPEED
LOad Type
Motor Wt. 12 LB   Enclosure TEFC   Lubrication POLYREX EM
Nameplate 081044   Mounting B3   Rotation REV
Shaft Diam.     Cust Part No.     Packaging N/A
      Winding QT6341   Carton Label IEC
      Group 3   Iris
Paint BLUE (ENAMEL)   Hazardous Location NONE   Test Card
1/4HP LEESON 1700RPM D63 IP55 3PH IEC MOTOR 192011
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 192011.00
Stock # 192011
Price: $144.00
Compare At: $319.00
