1/2HP LEESON 1140RPM 56C TENV 3PH WG SST MOTOR 191419.40

Catalog Number:  191419.40
Model Number:  C6T11NC48A
Description:  1/2HP,1140RPM,56C,TENV,WASHGUARD SST,3PH,60HZ
Ship Weight:  29 lbs.

LEESON WASHGUARD SST built with all stainless steel external components to prevent corrosion and well sealed against moisture and condensation to protect internal components, the WASHGUARD SST all-stainless motors are able to withstand the sever wash-down environments found in the food processing, chemical processing and beverage industries.

Mechanical Protection Features: All exterior components - frame, base, endshields, fan guard, shaft, hardware, conduit box and cover - are made from 300 series stainless steel for maximum corrosion resistance. Nameplate data is permanently laser-etched into the motor frame-no Mylar nameplate that can wash off or riveted metal nameplate to trap dirt. No paint or any type of coating is used on the exterior of the motor.

Standards and Approvals: UL component recognized, file number E57948, guide number PRGY2, Energy efficiency ratings are verified by and independent testing laboratory. CSA Energy Efficiency Verification Program, report number EEV78720-1. Construction is CSA Certified for safety report number LR33543. Motor is CE marked for European acceptance

Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 2.1-2 F.L. Amps 1 F.L. Amps 1.9/.95
S. F Amps 2.2-2.1 S. F Amps 1.05 S. F Amps 2/1
RPM 1800 Hertz 60/50
KW .37 Model # C6T11NC48A
Frame 56C Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code K
Insul Class F Protection NOT Therm.Prot.
Eff 100% 80 Eff 75%   PF 59
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6205
CC Number EXEMPT CE Yes Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 33 LB Enclosure TENV Lubrication POLYREX EM
Nameplate 2520710-001-S01 Mounting C FACE Rotation REV
Assembly   Shaft Dia. 5/8 IN Ext. Diag. 005010.01
Cust Part No   Outline 191419.40-S01 Ext. Diag2
1/2HP LEESON 1140RPM 56C TENV 3PH WG SST MOTOR 191419.40
Click Image to Enlarge
Manufacturer Part Number: 191419.40
Stock # 191419
