50HP LEESON 1780RPM 326TC TEFC 3PH WATTSAVER MOTOR 171833.60

50HP LEESON 1780RPM 326TC TEFC 3PH WATTSAVER MOTOR 171833.60

Picture is for reference only.

Part Number:

171833.60

Model/Spec Number:

326T17WK1

Manufacturer:

Leeson Obsolete
171833.60 LEESON 50HP WATTSAVER Motor is designed specifically to meet severe duty environments that you may find in applications such as chemical plants, foundries, pulp and paper mills, waste management facilities and above ground mines.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

612 lbs

Dimensions:

12 x 18 x 12 inches

HS Code:

8501.52.0000

UPC:

691720045886

Technical Details

Brand:

Leeson

Application:

Severe Duty

Output HP:

50

Output KW:

37

Output RPM:

1780

Frame Size NEMA:

326TC

Mount NEMA:

C Face With Base

Enclosure NEMA:

TEFC

Enclosure IEC:

IP54

Voltage:

230/460
