3HP LEESON 1200RPM 213T TEFC 3PH WATTSAVER MOTOR 171634.60

Catalog Number:  171634.60 - FREE Ground Shipping in USA
Model Number:  C213T11FW1
Description:  3HP,1200RPM,213T,TEFC,3PH,SEVERE DUTY
Ship Weight:  180 lbs.

LEESON Three Phase WATTSAVER e Plus Severe Duty Motor is used in severe duty environments that you may find in foundries, pulp, paper mills, waste management facilities, above ground mines, refineries or other applications that demand corrosion protection for long motor life and dependability.

FEATURES:

  • Full cast iron construction
  • Inverter rated insulation system
  • NEMA Premium efficiency rating with a three year warranty
  • 1 3/8" Keyed output shaft
  • Epoxy painted
  • Shaft seals both ends
  • Internal corrosion protection
  • IP55 enclosure protection
  • Division 2 CSA certification for hazardous locations:
  • Class 1 Groups A, B, C,D, Temperature Code T2B
  • Non-USA manufactured, CN
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 9.8 - 9.4 F.L. Amps 4.7 F.L. Amps 8.4/4.2
S. F Amps 10.4 S. F Amps 5.4 S. F Amps
RPM 1200 Hertz 60/50
HP 3 Duty CONTINUOUS TYPE TF
KW 2.24 Model # C213T11FW1AA
Frame 213T Serv. Factor 1.25 Phase 3
Max Amb 40 Design B Code K
Insul Class F Protection NOT Therm.Prot.
Eff 100% 89.5 Eff 75%   PF 64.8
UL V-INS, CONST UL REC CSA No Bearing OPE 6306
CC Number NONE CE Yes Bearing PE 6308
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 180 LB Enclosure TEFC Lubrication STANDARD
Nameplate 92970 Mounting RIGID Rotation REV
3HP LEESON 1200RPM 213T TEFC 3PH WATTSAVER MOTOR 171634.60
Click Image to Enlarge
Image for quick referance only
Manufacturer Part Number: 171634.60
Stock # 171634.60
Price: $921.00
Compare At: $1,997.00
