10HP LEESON 3540RPM 215T TEFC 3PH WATTSAVER MOTOR 171617.60

Catalog Number:  171617.60
Model Number:  C215T34FW1
Description:  10HP,3540RPM,215T,TEFC,3PH,SEVERE DUTY
Ship Weight:  190 lbs.

This Leeson Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

LEESON Three Phase Severe Duty WATTSAVER Plus Electric Motor is designed specifically to meet severe duty environments that you may find in applications such as chemical plants, foundries, pulp and paper mills, waste management facilities and above ground mines.

FEATURES:

  • Full cast iron construction
  • Inverter rated insulation system
  • 1 3/8" shaft output diameter
  • Epoxy painted
  • Shaft seals both ends
  • Internal corrosion protection
  • IP 55 enclosure protection
  • Division 2 CSA certification for hazardous locations, Class 1 Groups A, B, C, D, temperature Code T2B
  • 3-year warranty
  • Non-USA Manufactured, CN
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 26-23 F.L. Amps 11.5 F.L. Amps 20.6/13.3
S. F Amps 26.4 S. F Amps 13.2 S. F Amps
RPM 3600 Hertz 60/50
HP 10 Duty CONTINUOUS TYPE TF
KW 7.50 Model # C215T34FW1AAA
Frame 215T Serv. Factor 1.25 Phase 3
Max Amb 40 Design NO DESIGN CODE Code H
Insul Class F Protection NOT Therm.Prot.
Eff 100% 91.7 Eff 75%   PF 88.5
UL V-INS, CONST UL REC CSA No Bearing OPE NONE
CC Number NONE CE Yes Bearing PE NONE
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 190 LB Enclosure TEFC Lubrication STANDARD
Nameplate 92970 Mounting RIGID Rotation REV
10HP LEESON 3540RPM 215T TEFC 3PH WATTSAVER MOTOR 171617.60
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 171617.60
Stock # 171617
Price: $956.00
Compare At: $2,413.00
