7.5HP LEESON 3600RPM 213TC TEFC 3PH MOTOR 141120

LEESON G131165.00 has been Superseded by 141120.00.

Catalog Number:  141120.00
Model Number: C213T34WK6
Description:  7.5HP,3600RPM,213TC,TEFC,3PH,60HZ,WASHGUARD
Ship Weight:  140 lbs.

This LEESON Motor Can Ship Ground Freight ONLY!

For expedited needs please contact our sales team for freight options.

LEESON WASHGUARD WHITE EPOXY Three Phase Motors are designed for superior extended service in severe environments. Typical applications include food processing areas requiring frequent sanitation procedures using high pressure cleaning with concentrated caustic solutions, areas of high humidity and in chemical environments.

  • LEESON'S original moisture-shedding "duck" motor
  • USDA-approved white epoxy finish
  • Stainless steel shaft, conduit box cover, nameplate, fan guard
  • Special gaskets, slingers and seals
  • Four endshield drains
  • IRIS insulation system
  • Moisture-resistant interior components
  • Meets IP55 enclosure protection
  • Three phase motors are suitable for use on VFDs
  • 10:1 ratio for constant or variable torque at 1:0 SF



Volts 230 Volts 460 Volts 190/380
F.L. Amps 17.8 F.L. Amps 8.9 F.L. Amps 15/7.5
S. F Amps 20 S. F Amps 10 S. F Amps 16.6/8.3
RPM 3600 Hertz 60/50
HP 7 1/2 Duty CONTINUOUS TYPE TF
KW 5.6 Model # C213T34WK6A
Frame 213TC Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code H
Insul Class F Protection NOT Therm.Prot.
Eff 100% 90.2 Eff 75%   PF 87
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6206
CC Number CC005A CE Yes Bearing PE 6309
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 140 LB Enclosure TEFC Lubrication STANDARD
Nameplate 081341 Mounting RIGID Rotation REV
7.5HP LEESON 3600RPM 213TC TEFC 3PH MOTOR 141120
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 141120.00
Stock # 141120
Price: $1,078.00
Compare At: $3,170.00
