10HP LEESON 3600RPM 215TC TEFC 3PH MOTOR 140823.00

Catalog Number: 140823.00 - FREE Ground Shipping in USA
Model Number: C215T34WK9
Description:  10HP,3600RPM,215TC,TEFC,3PH,EPOXY WASHGUARD
Ship Weight: 164 lbs.

LEESON Three Phase White Duck Washguard Epoxy Motor is designed for enhanced performance in wet, humid areas. Designed to meet the demanding washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

  • NEMA Premium efficiency rating with a three year warranty
  • The original moisture-shedding "duck" motor
  • Durable rolled steel frame
  • C-Face mounting provisions with rigid base
  • USDA-approved, high-gloss, white epoxy finish
  • 1-3/8" Keyed output shaft
  • 303 stainless-steel shaft and moisture-resistant shaft system
  • Frame, base, endshields, rotor, and interior components are protected by enamel and polyester compounds
  • High temperature, moisture resistant IRIS® insulation system
  • Cast, oversized conduit box with tough, high-temperature nitrile gaskets and stainless-steel cover and hardware
  • Excellent for applications requiring a motor that is "tropicalized"
  • Double-sealed, oversized bearings
  • Stainless-steel or white polypropylene fan guard on all Washguard frames.
  • Stainless-steel, “full-fact” nameplate
  • Four condensate drains in each endshield
  • Meets IP55 enclosure protection
  • Non-USA Manufactured, MX
Volts 230 Volts 460 Volts 190/380
F.L. Amps 23.6 F.L. Amps 11.8 F.L. Amps 21/10.5
S. F Amps 26 S. F Amps 13 S. F Amps 23.2/11.6
RPM 3600 Hertz 60/50
HP 10 Duty CONTINUOUS TYPE TF
KW 7.5 Model # C215T34WK9A
Frame 215TC Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code H
Insul Class F Protection NOT Therm.Prot.
Eff 100% 91.7 Eff 75%   PF 87
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 206
CC Number CC005A CE Yes Bearing PE 309
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 164 LB Enclosure TEFC Lubrication STANDARD
Nameplate 081341 Mounting RIGID Rotation REV
10HP LEESON 3600RPM 215TC TEFC 3PH MOTOR 140823.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 140823.00
Stock # 140823
Price: $1,612.00
Compare At: $3,741.00
