5HP LEESON 3510RPM 184T TEFC 3PH MOTOR 132202

LEESON G131775.00 has been Superseded by 132202.00

Catalog Number:  132202.00
Model Number: C184T34WB5
Description:  5HP,3510RPM,184T,TEFC,3PH,60HZ,EPOXY WASHGUARD
Ship Weight: 89 lbs.

This LEESON Motor Can Ship Ground Freight ONLY!

For expedited needs please contact our sales team for freight options.

LEESON WASHGUARD WHITE EPOXY Three Phase Motors are designed for superior extended service in severe environments. Typical applications include food processing areas requiring frequent sanitation procedures using high pressure cleaning with concentrated caustic solutions, areas of high humidity and in chemical environments.

  • LEESON'S original moisture-shedding "duck" motor
  • USDA-approved white epoxy finish
  • Stainless steel shaft, conduit box cover, nameplate, fan guard
  • Special gaskets, slingers and seals
  • Four endshield drains
  • IRIS insulation system
  • Moisture-resistant interior components
  • Meets IP55 enclosure protection
  • Three phase motors are suitable for use on VFDs
  • 10:1 ratio for constant or variable torque at 1:0 SF



Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 13-12 F.L. Amps 6 F.L. Amps 14/7
S. F Amps 15-14 S. F Amps 7 S. F Amps 16/8
RPM 3600 Hertz 60/50
HP 5 Duty CONTINUOUS TYPE TF
KW 3.70 Model # C184T34WB5A
Frame 184T Serv. Factor 1.25 Phase 3
Max Amb 40 Design A Code K
Insul Class F Protection NOT Therm.Prot.
Eff 100% 88.5 Eff 75%   PF 89
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6205
CC Number NONE CE Yes Bearing PE 6206
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 89 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 081341 Mounting RIGID Rotation REV
5HP LEESON 3510RPM 184T TEFC 3PH MOTOR 132202
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 132202.00
Stock # 132202
Price: $780.00
Compare At: $2,105.00
Quantity:
