5HP LEESON 1800RPM 184TC TEFC 3PH MOTOR 132201.00

Catalog Number:  132201.00 - FREE Ground Shipping in USA
Model Number: C184T17WK15
Description:  5HP,1800RPM,184TC,TEFC,3PH,EPOXY WASHGUARD
Ship Weight:  90 lbs.

LEESON Three Phase White Duck Washguard Epoxy Motor is designed for enhanced performance in wet, humid areas. Designed to meet the demanding washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

  • NEMA Premium efficiency rating with a three year warranty
  • The original moisture-shedding "duck" motor
  • Durable rolled steel frame
  • C-Face mounting provisions with rigid base
  • USDA-approved, high-gloss, white epoxy finish
  • 1-1/8" Keyed output shaft
  • 303 stainless-steel shaft and moisture-resistant shaft system
  • Frame, base, endshields, rotor, and interior components are protected by enamel and polyester compounds
  • High temperature, moisture resistant IRIS® insulation system
  • Cast, oversized conduit box with tough, high-temperature nitrile gaskets and stainless-steel cover and hardware
  • Excellent for applications requiring a motor that is "tropicalized"
  • Double-sealed, oversized bearings
  • Stainless-steel or white polypropylene fan guard on all Washguard frames.
  • Stainless-steel, “full-fact” nameplate
  • Four condensate drains in each endshield
  • Meets IP55 enclosure protection
  • Non-USA Manufactured, MX
Volts 208-230 Volts 460 Volts
F.L. Amps 13.7-12.6 F.L. Amps 6.3 F.L. Amps
S. F Amps 15.5-14.4 S. F Amps 7.2 S. F Amps
RPM 1800 Hertz 60
HP 5 Duty CONTINUOUS TYPE TF
KW 3.70 Model # C184T17WK15A
Frame 184TC Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code J
Insul Class F Protection NOT Therm.Prot.
Eff 100% 89.5 Eff 75%   PF 83.1
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6205
CC Number CC005A CE Yes Bearing PE 6206
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 90.5 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 081341 Mounting RIGID C Rotation REV
5HP LEESON 1800RPM 184TC TEFC 3PH MOTOR 132201.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 132201.00
Stock # 132201
Price: $924.00
Compare At: $2,254.00
