7.5-10HP LEESON 3450RPM 184TZ DPAO 3PH MOTOR 131850

Catalog Number: 131850.00
Model Number: C184T34DB9
Description:  7.5-10HP,3450RPM,184TZ,DPAO,3PH,60HZ
Ship Weight:  88 lbs.

This Leeson Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Used on Crop Dryer with air over/fan on shaft designs.

FEATURES:

  • Steel frame
  • Rigid base
  • Dripproof air over
  • 1 1/8" output shaft diameter
  • Class “F” insulation system
  • Automatic Overload protected
  • 1.0 Service Factor
  • Keyed shaft with 1/4-20 UNC tapped hole on end
  • 34” long leads
  • Motor venting protected against insects and rodents
  • Double sealed ball bearings
  • Footnotes: S,MX
Volts 208-230 Volts 460 Volts 208-230/460
F.L. Amps 18.5-17.5 F.L. Amps 8.7 F.L. Amps 25-23.5/11.7
S. F Amps   S. F Amps   S. F Amps
RPM 3600 Hertz 60/60
HP 7 1/2 Duty AIROVER TYPE TD
KW 5.60 Model # C184T34DB9
Frame 184TZ Serv. Factor 1.0 Phase 3
Max Amb 40 Design B Code J
Insul Class F Protection AUTOMATIC Therm.Prot. 9700K46-33
Eff 100% 89.5 Eff 75%   PF 90.5
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6205
CC Number EXEMPT CE Yes Bearing PE 6206
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 88 LB Enclosure DP Lubrication POLYREX EM
Nameplate 081284 Mounting RIGID Rotation REV
Assembly   Shaft Dia. 1 1/8 IN Ext. Diag. 005010.20
7.5-10HP LEESON 3450RPM 184TZ DPAO 3PH MOTOR 131850
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 131850.00
Stock # 131850
Price: $554.00
Compare At: $1,629.00
