5HP LEESON 3500RPM 182TC DP 3PH MOTOR G131779

LEESON 131779.00 has been superseded by G131779.00

LEESON Catalog Number:  G131779.00
Description:  5HP,3500RPM,182TC,DP,3PH,60HZ
Ship Weight:  63 lbs.

DP Models: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

Features Include:

  • Durable rolled steel frame
  • High-quality ball bearings
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA approval.
  • Warranty – 12 months from date of first use or 18 months from date of manufacture, whichever comes first.
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 13.2-12.2 F.L. Amps 6.1 F.L. Amps 9.4/4.7
S. F Amps 14.6-14 S. F Amps 7 S. F Amps 10.6/5.3
RPM 3600 Hertz 60/50
HP 5 Duty CONTINUOUS TYPE TD
KW 3.70 Model Number C182T34DC11A A
Frame 182TC Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code J
Insul Class F Protection NOT Therm.Prot.
Eff 100% 85.5 Eff 75%   PF 90
UL Yes CSA Yes Bearing OPE 6205
CC Number NONE CE Yes Bearing PE 6206
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 63 LB Enclosure DP Lubrication POLYREX EM
Nameplate 081284 Mounting C FACE Rotation REV
5HP LEESON 3500RPM 182TC DP 3PH MOTOR G131779
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: G131779.00
Stock # G131779
