3HP LEESON 1740RPM 182TC TEFC 3PH BRAKE MOTOR 131610
LEESON 131610.00 has been superseded by 132479.00
| Catalog Number: | 131610.00 |
| Description: | 3HP,1740RPM,182TC,TEFC,3PH,60HZ,BRAKE |
| Ship Weight: | 72 lbs. |
| Volts | 208-230 | Volts | 460 | Volts | |
| F.L. Amps | 9.2-9 | F.L. Amps | 4.5 | F.L. Amps | |
| S. F Amps | 10-9.8 | S. F Amps | 4.9 | S. F Amps | |
| RPM | 1800 | Hertz | 60 | ||
| HP | 3 | Duty | CONTINUOUS | TYPE | TF |
| KW | 2.24 | Model # | C182T17FC28C | ||
| Frame | 182TC | Serv. Factor | 1.15 | Phase | 3 |
| Max Amb | 40 | Design | C | Code | K |
| Insul Class | F | Protection | NOT | Therm.Prot. | |
| Eff 100% | 82.5 | Eff 75% | PF | 75.5 | |
| UL | Yes | CSA | Yes | Bearing OPE | 6205 |
| CC Number | EXEMPT | CE | Yes | Bearing PE | 6206 |
| Load Type | Inverter Type | Speed Range | NONE | ||
| Motor Wt. | 72 LB | Enclosure | TEFC | Lubrication | POLYREX EM |
| Nameplate | 081284 | Mounting | C FACE | Rotation | REV |
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 131610.00
Stock # 131610
