5HP LEESON 1760RPM 184JM DP 3PH ULTIMATE-E PUMP MOTOR G131563.00
5HP LEESON 1760RPM 184JM DP 3PH ULTIMATE-E PUMP MOTOR G131563.00
Picture is for reference only.
Part Number:
G131563.00Model/Spec Number:
C184T17DK28AAManufacturer:
Leeson ObsoleteClick below to view suggested functional replacement.
Shipping Details
Weight:
74 lbsDimensions:
13 x 22 x 13 inchesHS Code:
8501.52.4000Technical Details
Specifications
Brand: | Leeson |
Application: | Closed Coupled |
Output HP: | 5 |
Output KW: | 3.7 |
Output RPM: | 1760 |
Frame Size NEMA: | 184JM |
Mount NEMA: | C Face With Base |
Enclosure NEMA: | DP |
Enclosure IEC: | IP22 |
Voltage: | 230/460 |
Documentation
Additional Information
| Volts | 208-230 | Volts | 460 | Volts | |
| F.L. Amps | 14-13.2 | F.L. Amps | 6.6 | F.L. Amps | |
| S. F Amps | 16-15 | S. F Amps | 7.5 | S. F Amps | |
| RPM | 1800 | Hertz | 60 | ||
| HP | 5 | Duty | CONTINUOUS | TYPE | TD |
| KW | 3.70 | Model Number | C184T17DK28A A | ||
| Frame | 184JM | Serv. Factor | 1.15 | Phase | 3 |
| Max Amb | 40 | Design | B | Code | J |
| Insul Class | F | Protection | NOT | Therm.Prot. | |
| Eff 100% | 87.5 | Eff 75% | PF | 81 | |
| UL | Yes | CSA | Yes | Bearing OPE | 6205 |
| CC Number | EXEMPT | CE | Yes | Bearing PE | 6207 |
| Load Type | Inverter Type | Speed Range | NONE | ||
| Motor Wt. | 74 LB | Enclosure | DP | Lubrication | POLYREX EM |
| Nameplate | 081284 | Mounting | RIGID | Rotation | REV |
