1.5HP LEESON 1750RPM 145TC TEFC 3PH BRAKE MOTOR 122252.00

Catalog Number:  122252.00
Model Number:  C145T17FC127A
Description:  1.5HP,1750RPM,145TC,TEFC,3PH,60HZ,BRAKE
Ship Weight:  51 lbs.

LEESON Fail-safe positive, stop and hold brakemotors. Brakes are spring set. Load stopped automatically when power is turned off. LEESON brakemotors feature a power off manual release for convenience, and for use in case of a power failure. The manual release resets automatically. The standard brake is manufactured by Stearns. The brake coil leads are brought into the conduit box of the motor for easy connection and may be connected to operate when power to the motor is shut off, or to be actuated independent of power to the motor.

FEATURES:

  • 7/8" shaft output diameter
Volts 208-230 Volts 460 Volts
F.L. Amps 4.6-4.8 F.L. Amps 2.4 F.L. Amps
S. F Amps 5.2-5.4 S. F Amps 2.7 S. F Amps
RPM 1800 Hertz 60
HP 1 1/2 Duty CONTINUOUS TYPE TF
KW 1.12 Model # C145T17FC127A
Frame 145 C Serv. Factor 1.15 Phase 3
Max Amb 40 Design C Code L
Insul Class F Protection NOT Therm.Prot. 9700K46
Eff 100% 86.5 Eff 75%   PF 67.7
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 51 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 993500 Mounting ROUND Rotation REV
Assembly   Shaft Dia. 7/8 IN Ext. Diag. 005010.28
Cust Part No   Outline 028845-800 Ext. Diag2
Packaging B     Winding T634341
Carton Label Leeson Brakemotor     GROUP:
Iris   Paint GREEN - LEESON WATTSAVER Test Card 01
1.5HP LEESON 1750RPM 145TC TEFC 3PH BRAKE MOTOR 122252.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 122252.00
Stock # 122252
Price: $857.00
Compare At: $2,075.00
