122186.00 LEESON 1HP 3PH EPOXY WASHDOWN PUMP MOTOR C143T17WK15

1HP LEESON 1760RPM 143JM TEFC 3PH EPOXY WASHDOWN PUMP MOTOR 122186.00

Part Number:

122186.00

Model/Spec Number:

C143T17WK15

Manufacturer:

Leeson Obsolete

122186.00 LEESON 1HP Three Phase White Duck Epoxy Washguard JM Pump Motor is designed for demanding pump applications requiring a JM shaft in wet, humid areas. Designed to meet the industrial washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

Item Discontinued

Click below to request an agent review potential options.

Shipping Details

Free No Rush Shipping

Weight:

49 lbs

Dimensions:

13 x 22 x 13 inches

HS Code:

8501.52.4000

UPC:

691720052020

Technical Details

Specifications

Brand:	Leeson
Application:	Closed Coupled
Output HP:	1
Output KW:	0.75
Output RPM:	1760
Frame Size NEMA:	143JM
Mount NEMA:	C Face With Base
Enclosure NEMA:	TEFC
Enclosure IEC:	IP55
Voltage:	208-230/460

Documentation

Product Information Packet

Additional Information

LEESON Three Phase White Duck Epoxy Washguard JM Pump Motor is designed for demanding pump applications requiring a JM shaft in wet, humid areas. Designed to meet the industrial washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

NEMA Premium efficiency rating with a three year warranty
The original moisture-shedding "duck" motor
USDA-approved, high-gloss, white epoxy finish
303 stainless-steel shaft and moisture-resistant shaft system
Frame, base, endshields, rotor, and interior components are protected by enamel and polyester compounds
High temperature, moisture resistant IRIS® insulation system
Oversized conduit box with tough, high-temperature nitrile gaskets and stainless-steel cover and hardware
Excellent for applications requiring a motor that is "tropicalized"
Double-sealed, oversized bearings
Stainless-steel or white polypropylene fan guard on all Washguard frames.
Stainless-steel, “full-fact” nameplate
Four condensate drains in each endshield
