3HP LEESON 3600RPM 145JM DP 3PH MOTOR 122081.00

Catalog Number:  122081.00 - FREE Ground Shipping in USA
Model Number:  C145T34DK17
Description:  3HP,3600RPM,145JM,DP,3PH,60HZ,JM PUMP
Ship Weight:  50 lbs.

LEESON 3-Phase WATTSAVER Pump Motors are designed for continuous duty service on close-coupled pumps using NEMA JM mounting provisions. All motors have a rigid mounting base and NEMA JM pump Shaft.


  • Made in USA
  • Steel frame
  • Open drip-proof construction
  • Cooling air exhausts at the shaft end for maximum cooling
  • Oversized locked bearing on shaft end limits axial shaft movement
  • High efficiency copper windings with NEMA 1.15 service factors
  • Uses drip cover kit 175932.00
  • UL and CSA recognized designs
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 8-7.2 F.L. Amps 3.6 F.L. Amps 6.2/3.1
S. F Amps 8.8-8.0 S. F Amps 4.0 S. F Amps
RPM 3600 Hertz 60/50
KW 2.24
Frame 145JM Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code K
Insul Class F Protection NOT Therm.Prot.
Eff 100% 86.5 Eff 75%   PF 88
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number CC005A CE Yes Bearing PE 6206
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 50 LB Enclosure DP Lubrication STANDARD
Nameplate 993500 Mounting RIGID Rotation REV
Assembly   Shaft Dia.   Ext. Diag. 005010.01
Cust Part No   Outline 607-0208-825 Ext. Diag2
Packaging B Outline Dash No   Winding T632175
Carton Label INDIVIDUAL     GROUP :
Iris   Paint BLUE - LEESON (ENAMEL) Test Card 01
3HP LEESON 3600RPM 145JM DP 3PH MOTOR 122081.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 122081.00
Stock # 122081
Price: $392.00
Compare At: $1,151.00
