2HP LEESON 3600RPM 145T EPFC 3PH MOTOR 121916.00

Catalog Number:  121916.00 - FREE Ground Shipping in USA
Model Number:  A145T34XB27
Description:  2HP,3600RPM,145T,EPFC,3PH,60HZ
Ship Weight:  55 lbs.

LEESON Three Phase Explosion Proof Motor is designed and approved for applications in hazardous environments having certain explosive gases or materials present.

FEATURES:

  • Made in USA
  • This motor is NOT inverter rated
  • Motors with automatic overload protectors cannot be used on VFDs.
  • Automatic overload protection
  • 7/8" Keyed output shaft
  • Durable rolled steel frame
  • Meets all UL and CSA safety requirements
  • Double shielded ball bearings
  • NEMA 1.0 Service Factor
  • Explosion-proof conduit box included
  • Warranty: 12 months from the date of purchase or 18 months from the date of manufacture, whichever comes first

MOTOR RATING:  (Click on Files for LEESON's Hazardous Ratings Chart)

  • DIVISION I, DIVISION II: CLASS I, GROUPS C&D; CLASS II, GROUPS F&G;
  • MEETS TEMPERATURE CODE T3B
  • NO LEESON motors are listed for Class I, Group A or B
  • Division I areas are environments where a hazard is present continuously or would be subject to fire or explosion if the hazard was present as a result of an accident or uncommon occurrence.
  • Division II areas are environments where the threat of fire or explosion is not normally present and not likely to result in the event of an abnormal occurrence.
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 5.6-5.2 F.L. Amps 2.6 F.L. Amps 4.8/2.4
S. F Amps   S. F Amps   S. F Amps
RPM 3600 Hertz 60/50
HP 2 Duty CONTINUOUS TYPE TX
KW 1.49 Model # A145T34XB25A
Frame 145T Serv. Factor 1.0 Phase 3
Max Amb 40 Design B Code L
Insul Class B Protection AUTOMATIC Therm.Prot. CWJ53KL
Eff 100% 86.5 Eff 75%   PF 83
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 203
CC Number CC005A CE No Bearing PE 205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 55 LB Enclosure EPFC Lubrication POLYREX EM
Nameplate   Mounting RIGID Rotation REV
2HP LEESON 3600RPM 145T EPFC 3PH MOTOR 121916.00
Click Image to Enlarge
PICTURE IS FOR QUICK REFERENCE ONLY
Manufacturer Part Number: 121916.00
Stock # 121916
Price: $555.00
Compare At: $1,399.00
