1.5HP LEESON 1800RPM 145T TEFC 3PH MOTOR 121869.00

Catalog Number: 121869.00 - FREE Ground Shipping in USA
Model Number: C145T17WB23
Description:  1.5HP,1800RPM,145T,TEFC,3PH,EPOXY WASHGUARD
Ship Weight: 51 lbs.

LEESON Three Phase White Duck Washguard Epoxy Motor is designed for enhanced performance in wet, humid areas. Designed to meet the demanding washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

  • Made in the USA
  • The original moisture-shedding "duck" motor
  • Durable rolled steel frame
  • USDA-approved, high-gloss, white epoxy finish
  • NEMA Premium efficiency rating with a three year warranty
  • 7/8" Keyed output shaft
  • 303 stainless-steel shaft and moisture-resistant shaft system
  • Frame, base, endshields, rotor, and interior components are protected by enamel and polyester compounds
  • High temperature, moisture resistant IRIS® insulation system
  • Cast, oversized conduit box with tough, high-temperature nitrile gaskets and stainless-steel cover and hardware
  • Excellent for applications requiring a motor that is "tropicalized"
  • Double-sealed, oversized bearings
  • Stainless-steel or white polypropylene fan guard on all Washguard frames.
  • Stainless-steel, “full-fact” nameplate
  • Four condensate drains in each endshield
  • Meets IP55 enclosure protection



Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 4.8 F.L. Amps 2.4 F.L. Amps 5.6/2.8
S. F Amps 5.4 S. F Amps 2.7 S. F Amps 6/3
RPM 1800 Hertz 60/50
HP 1 1/2 Duty CONTINUOUS TYPE TF
KW 1.12 Model # C145T17WB23A
Frame 145T Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code L
Insul Class F Protection NOT Therm.Prot.
Eff 100% 86.5 Eff 75%   PF 67.7
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number NONE CE Yes Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 44 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 081341 Mounting RIGID Rotation REV
1.5HP LEESON 1800RPM 145T TEFC 3PH MOTOR 121869.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 121869.00
Stock # 121869
Price: $420.00
Compare At: $1,102.00
