1HP LEESON 1745RPM 143T TEFC 3PH EPOXY MOTOR 121865

LEESON G120585.00 has been Superseded by 121865.00

Catalog Number: 121865.00
Model Number: C143T17WB4
Description:  1HP,1745RPM,143T,TEFC,3PH,EPOXY WASHGUARD
Ship Weight: 39 lbs.

LEESON WASHGUARD WHITE EPOXY Three Phase Motors are designed for superior extended service in severe environments. Typical applications include food processing areas requiring frequent sanitation procedures using high pressure cleaning with concentrated caustic solutions, areas of high humidity and in chemical environments.

  • LEESON'S original moisture-shedding "duck" motor
  • USDA-approved white epoxy finish
  • Stainless steel shaft, conduit box cover, nameplate, fan guard
  • Special gaskets, slingers and seals
  • Four endshield drains
  • IRIS insulation system
  • Moisture-resistant interior components
  • Meets IP55 enclosure protection
  • Three phase motors are suitable for use on VFDs
  • 10:1 ratio for constant or variable torque at 1:0 SF



Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 3.2-3.2 F.L. Amps 1.6 F.L. Amps 3.4-3.4/1.7
S. F Amps 3.8-3.8 S. F Amps 1.9 S. F Amps 4.2-4.2/2.1
RPM 1800 Hertz 60/50
HP 1 Duty CONTINUOUS TYPE TF
KW 0.75 Model # C143T17WB4A
Frame 143T Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code N
Insul Class F Protection NOT Therm.Prot.
Eff 100% 85.5 Eff 75%   PF 68.5
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number CC005A CE Yes Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 38.85 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 081341 Mounting RIGID Rotation REV
1HP LEESON 1745RPM 143T TEFC 3PH EPOXY MOTOR 121865
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 121865.00
Stock # 121865
Price: $338.00
Compare At: $953.00
