2HP LEESON 3500RPM 145JM DP 3PH ULTIMTE-E PUMP MOTOR G121853.00

Picture is for reference only.

Part Number:

G121853.00

Model/Spec Number:

C145T34DK13A

Manufacturer:

Leeson Obsolete

G121853.00 LEESON Three Phase Premium JM Pump Motor is designed for continuous duty service on close-coupled pumps using NEMA JM mounting provisions.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

44 lbs

Dimensions:

14 x 22 x 14 inches

HS Code:

8501.52.4000

Technical Details

Specifications

Brand:	Leeson
Application:	Closed Coupled
Output HP:	2//1.5
Output KW:	1.5
Output RPM:	3500
Frame Size NEMA:	145JM
Mount NEMA:	C Face With Base
Enclosure NEMA:	DP
Enclosure IEC:	IP22
Voltage:	208-230/460//190/380

Documentation

Motor Drawing REF DASH-756

Connection Diagram

Additional Information

Volts 208-230 Volts 460 Volts 190/380 F.L. Amps 5.6-5.2 F.L. Amps 2.6 F.L. Amps 4.8/2.4 S. F Amps 6.25-5.8 S. F Amps 2.9 S. F Amps RPM 3600 Hertz 60/50 HP 2 Duty CONTINUOUS TYPE TD KW 1.49 Model Number C145T34DK13 A Frame 145JM Serv. Factor 1.15 Phase 3 Max Amb 40 Design B Code L Insul Class B Protection NOT Therm.Prot. Eff 100% 84 Eff 75% PF 85 UL Y-(LEESON UL REC) CSA Yes Bearing OPE 203 CC Number CE Yes Bearing PE 206 Load Type Inverter Type Speed Range NONE Motor Wt. 44 LB Enclosure DP Lubrication STANDARD Nameplate Mounting RIGID Rotation REV
