1HP LEESON 1170RPM 145T DP 3PH WATTSAVER MOTOR 121517.00

Catalog Number:  121517.00 Made in USA
Model Number:  C145T11DB7B
Description:  1HP,1170RPM,145T,DP,3PH,60/50HZ,WATTSAVER
Ship Weight:  44 lbs.

APPLICATIONS: For use where water and dust exposure is minimal. Ideally suited for use on pumps, compressors, blowers, fans and other standard industrial applications. LEESON WATTSAVER line of premium efficiency motors are now inverter capable. LEESON's unique IRIS voltage-spike-resistant insulation system is standard at no extra cost. WATTSAVER motors carry a three-year warranty in general purpose and inverter fed applications. This motor meets or exceeds most utility rebate programs and the EPACT federally mandated efficiency levels. The efficiency ratings have been verified to IEEE 112B test standards by LEESON's NVLAP-Certified lab.

FEATURES:

  • Made in USA
  • 7/8" shaft output diameter
  • Premium efficient
  • Inverter-rated
  • Nameplated for 50 Hz operation
  • 3-year warranty on Premium efficient motors
  • Class F insulation systems
  • Shielded ball bearings for direct coupled applications
  • UL recognized and CSA certified
Volts 208-230 Volts 460 Volts 208-230/460
F.L. Amps 3.8-3.8 F.L. Amps 1.9 F.L. Amps 4.4-4.4/2.2
S. F Amps 4.2-4.2 S. F Amps 2.1 S. F Amps 5-5/2.5
RPM 1200 Hertz 60/50
HP 1 Duty CONTINUOUS TYPE TD
KW .75 Model Number C145T11DB7B
Frame 145T Serv. Factor 1.25 Phase 3
Max Amb 40 Design B Code K
Insul Class F Protection AUTOMATIC Therm.Prot. 9700K46
Eff 100% 82.5 Eff 75%   PF 60
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number NONE CE Yes Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 44 LB Enclosure DP Lubrication POLYREX EM
Nameplate 993500 Mounting RIGID Rotation REV
1HP LEESON 1170RPM 145T DP 3PH WATTSAVER MOTOR 121517.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 121517.00
Stock # 121517
Price: $301.00
Compare At: $877.00
