2HP LEESON 3490RPM 145T DP 3PH WATTSAVER MOTOR 121515.00

Catalog Number:  121515.00 - FREE Ground Shipping in USA
Model Number:  C145T34DB15 C
Description:  2HP,3490RPM,145T,DP,3PH,60/50HZ,WATTSAVER
Ship Weight:  45 lbs.

LEESON WATTSAVER motor carries a three-year warranty in general purpose and inverter fed applications These motors meet or exceed most utility rebate programs and the EPACT federally mandated efficiency levels. The efficiency ratings have been verified to IEEE 112B test standards by LEESON's NVLAP-Certified lab.

FEATURES:

  • Made in USA
  • 7/8" Keyed output shaft
  • Durable steel frame
  • Premium efficient motor with 3 year warranty
  • Inverter-rated
  • Rated for 50 Hz operation
  • Class F insulation systems
  • Shielded ball bearings for direct coupled applications
  • UL recognized and CSA certified
Volts 230   Volts 460   Volts 190/380
FL Amps 5.2-4.8   FL Amps 2.4   FL Amps 5.8/2.9
SF Amps 6-5.6   SF Amps 2.8   SF Amps 6.8/3.4
RPM 3600   Hertz 60/50
HP 2   Duty CONTINUOUS   Type TD
KW 1.49   SF 1.25   Phase 3
Frame 145T   Design B   KVA Code L
Ambient 40   Protection NOT   Therm.Prot. 9700K46
Insulation Class F   Eff(75%)     PF 88
Eff(100%) 86.5   CSA Y   Bearing OPE 6203
UL Y-(LEESON UL REC)   CE Y   Bearing PE 6205
CC Number CC005A   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 45 LB   Enclosure DP   Lubrication POLYREX EM
Nameplate 993500   Mounting RIGID   Rotation REV
Shaft Diam. 7/8 IN   Cust Part No.     Packaging B
      Winding T632174   Carton Label Leeson Wattsaver
      Group 3   Iris
Paint GREEN - LEESON WATTSAVER   Hazardous Location NONE   Test Card 01
2HP LEESON 3490RPM 145T DP 3PH WATTSAVER MOTOR 121515.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 121515.00
Stock # 121515
Price: $328.00
Compare At: $931.00
