1.5HP LEESON 3490RPM 143T DP 3PH WATTSAVER MOTOR 121514.00

Catalog Number:  121514.00 Made in USA
Model Number:  C143T34DB4C
Description:  1.5HP,3490RPM,143T,DP,3PH,60/50HZ,WATTSAVER
Ship Weight:  39 lbs.

APPLICATIONS: For use where water and dust exposure is minimal. Ideally suited for use on pumps, compressors, blowers, fans and other standard industrial applications. LEESON WATTSAVER motors carry a three-year warranty in general purpose and inverter fed applications. LEESON's unique IRIS voltage-spike-resistant insulation system is standard at no extra cost. These motors meet or exceed most utility rebate programs and the EPACT federally mandated efficiency levels. The efficiency ratings have been verified to IEEE 112B test standards by LEESON's NVLAP-Certified lab.

FEATURES:

  • Made in USA
  • 7/8" shaft output diameter
  • Steel frame
  • Premium efficient motor with 3 year warranty
  • Inverter-rated
  • Nameplated for 50 Hz operation
  • Class F insulation systems
  • Shielded ball bearings for direct coupled applications
  • UL recognized and CSA certified
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 4.4-4 F.L. Amps 2 F.L. Amps 4.8/2.4
S. F Amps 5.4-5 S. F Amps 2.5 S. F Amps 5.6/2.8
RPM 3600 Hertz 60/50
HP 1 1/2 Duty CONTINUOUS TYPE TD
KW 1.12 Model Number C143T34DB4C
Frame 143T Serv. Factor 1.25 Phase 3
Max Amb 40 Design B Code M
Insul Class F Protection AUTOMATIC Therm.Prot. 9700K46
Eff 100% 84 Eff 75%   PF 82
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number NONE CE Yes Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 39 LB Enclosure DP Lubrication POLYREX EM
Nameplate 993500 Mounting RIGID Rotation REV
1.5HP LEESON 3490RPM 143T DP 3PH WATTSAVER MOTOR 121514.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 121514.00
Stock # 121514
Price: $253.00
Compare At: $746.00
