2HP LEESON 1725RPM 145TC DP 1PH MOTOR 120992.00

Catalog Number:  120992.00
Model Number:  C145K17DK7H
Description:  2HP,1725RPM,145TC,DP,1PH,60HZ
Ship Weight:  48 lbs.

APPLICATIONS: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

FEATURES:

  • Made in USA
  • Durable rolled steel frame
  • High-quality ball bearings
  • Capacitor start/capcitor run design for reduced amperage
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA approval
  • 1 year warranty
Volts 115 Volts 208-230 Volts
F.L. Amps 21 F.L. Amps 10.5 F.L. Amps
S. F Amps 23 S. F Amps 11.5 S. F Amps
RPM 1800 Hertz 60
HP 2 Duty CONTINUOUS TYPE KD
KW 1.49 Model # C145K17DK7H
Frame J145TC Serv. Factor 1.15 Phase 1
Max Amb 40 Design L Code H
Insul Class B Protection NOT Therm.Prot.
Eff 100% 80 Eff 75%   PF 79
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE No Bearing PE 6205
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 48 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004003 Mounting RIGID C Rotation SELECTIVE CCW
2HP LEESON 1725RPM 145TC DP 1PH MOTOR 120992.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 120992.00
Stock # 120992
Price: $322.00
Compare At: $781.00
