1.5/.37HP LEESON 1725/850RPM 145T TEFC 460V 3PH MOTOR 120941

LEESON Catalog Number:  120941.00
Description:  1.5/.37HP,1725/850RPM,145T,TEFC,460V,3PH,60HZ,2-SPEED
Ship Weight:  39 lbs.

APPLICATIONS: LEESON Two Speed One Winding Variable Torque Electric Motors are designed for use in applications in which multiple speeds are required.

Variable torque motors have horsepower ratings that vary as the square of the speed, while torque varies directly with the speed. These motors are typically used on applications such as fans, blowers and centrifugal pumps.

Constant horsepower motors develop the same horsepower at all operating speeds, and the torque varies inversely with the speed. These motors are often used on machine tools, such as drills, lathes, punch presses and milling machines.

Volts 460 Volts   Volts 460
F.L. Amps 2.4 F.L. Amps   F.L. Amps 1
S. F Amps   S. F Amps   S. F Amps
RPM 1800 Hertz 60/60
HP 1 1/2 Duty CONTINUOUS TYPE TF
KW 1.12 Model # C145T48FB60D
Frame 145T Serv. Factor 1.0 Phase 3
Max Amb 40 Design NO DESIGN CODE Code J
Insul Class F Protection NOT Therm.Prot.
Eff 100%   Eff 75%   PF
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number NONE CE No Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 39 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 993500 Mounting RIGID Rotation REV
1.5/.37HP LEESON 1725/850RPM 145T TEFC 460V 3PH MOTOR 120941
Click Image to Enlarge
Manufacturer Part Number: 120941.00
Stock # 120941
