2/.5HP LEESON 1725/850RPM 145T TEFC 460V 3PH MOTOR 120940
|LEESON Catalog Number:||120940.00|
|Ship Weight:||39 lbs.|
This Leeson Motor is a Build To Order product and factory lead times are approximately 3-6 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales office for particulars.
Call for Availability
APPLICATIONS: LEESON Two Speed One Winding Variable Torque Electric Motors are designed for use in applications in which multiple speeds are required.
Variable torque motors have horsepower ratings that vary as the square of the speed, while torque varies directly with the speed. These motors are typically used on applications such as fans, blowers and centrifugal pumps.
Constant horsepower motors develop the same horsepower at all operating speeds, and the torque varies inversely with the speed. These motors are often used on machine tools, such as drills, lathes, punch presses and milling machines.
|F.L. Amps||3.2||F.L. Amps||F.L. Amps||1.3|
|S. F Amps||S. F Amps||S. F Amps|
|Eff 100%||79||Eff 75%||PF||74|
|UL||Y-(LEESON UL REC)||CSA||Yes||Bearing OPE||6203|
|CC Number||NONE||CE||No||Bearing PE||6205|
|Load Type||Inverter Type||Speed Range||NONE|
|Motor Wt.||39 LB||Enclosure||TEFC||Lubrication||POLYREX EM|
