Home > Electric Motors > ELECTRIC MOTORS SINGLE PHASE > LEESON Single Phase Motors > LEESON DP Single Phase Motors > 2HP LEESON 1800RPM 145T ODP 115/208-230V 1PH MOTOR 120879.00

2HP LEESON 1800RPM 145T ODP 115/208-230V 1PH MOTOR 120879.00

Catalog Number:  120879.00 - FREE Ground Shipping in USA
Model Number:  P145K17DB38F
Description:  2HP,1740RPM,145T,DP,115/208-230V,1PH,60HZ
Ship Weight:  54 lbs.

Motors specially suited for hot or cold pressure washer applicaitons and other single phase installations requiring minimum starting and running amperages.

Features:

  • Made in USA
  • 7/8" Keyed output shaft
  • Durable rolled steel frame
  • Manual Overload Protection
  • Capacitor Start and Run
  • Pressure washer duty
  • High-quality double shielded ball bearings
  • Dynamically balanced rotors
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA approval.
  • 12 months from the date of purchase or 18 months from the date of manufacture, whichever comes first
Volts 115 Volts 208-230 Volts
F.L. Amps 17.2 F.L. Amps 9.2-8.6 F.L. Amps
S. F Amps 19.8 S. F Amps 10.8-9.9 S. F Amps
RPM 1800 Hertz 60
HP 2 Duty CONTINUOUS TYPE KD
KW 1.49 Model # P145K17DB38F
Frame 145T Serv. Factor 1.15 Phase 1
Max Amb 40 Design L Code H
Insul Class B Protection MANUAL Therm.Prot. BRJ45DB
Eff 100% 79 Eff 75%   PF 95
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 54 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004004 Mounting RIGID Rotation SELECTIVE CCW
2HP LEESON 1800RPM 145T ODP 115/208-230V 1PH MOTOR 120879.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 120879.00
Stock # 120879
Price: $469.00
Compare At: $1,094.00
Quantity:
