3HP LEESON 3450RPM 145TC TEFC 1PH MOTOR 120824.00

Catalog Number:  120824.00 - FREE Ground Shipping in USA
Model Number: P145K34FC6 G
Description:  3HP,3450RPM,145TC,TEFC,1PH,60HZ
Ship Weight:  56 lbs.

LEESON Single Phase General Purpose Motor for use where exposure is limited to splashes of water, dust and/or where mild corrosives exist. Ideally, suited for use on pumps, compressors, blowers, fans, conveyors, machine tools and other direct or belt-driven applications. Designed for woodworking equipment such as table saws, planers, etc. Not for outdoor use without proper shielding or for use with harsh chemicals.

FEATURES:

  • Made in the USA
  • 7/8" Keyed output shaft
  • Durable rolled steel frame
  • Manual overload protection
  • Double-shielded ball bearings
  • Fully gasketed to prevent dust entry
  • Capacitor start/capacitor run design for reduced amperage
  • UL Recognized Component Listing and CSA approval
  • Warranty: 12 months from the date of purchase or 18 months from the date of manufacture, whichever comes first
Volts 230 Volts   Volts
F.L. Amps 13 F.L. Amps   F.L. Amps
S. F Amps   S. F Amps   S. F Amps
RPM 3600 Hertz 60
HP 3 Duty CONTINUOUS TYPE KF
KW 2.24 Model Number P145K34FC6G
Frame 145TC Serv. Factor 1.0 Phase 1
Max Amb 40 Design L Code J
Insul Class F Protection MANUAL Therm.Prot. BRJ42DB
Eff 100% 81.5 Eff 75%   PF 91
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 56 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 993500 Mounting ROUND Rotation SELECTIVE CCW
3HP LEESON 3450RPM 145TC TEFC 1PH MOTOR 120824.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 120824.00
Stock # 120824
Price: $490.00
Compare At: $1,235.00
