1HP LEESON 1740RPM 143TC TENV 3PH MOTOR 120760.00

5 IN STOCK
Catalog Number:  120760.00
Model Number:  C143T17VC1G
Description:  1HP,1740RPM,143TC,TENV,3PH,60HZ,EPOXY WASHGUARD
Ship Weight:  38 lbs.
Volts 208-230 Volts 460 Volts
F.L. Amps 3.2 F.L. Amps 1.6 F.L. Amps
S. F Amps 3.5 S. F Amps 1.75 S. F Amps
RPM 1800 Hertz 60
HP 1 Duty CONTINUOUS TYPE TN
KW 0.75 Model # C143T17VC1 G
Frame 143TC Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code M
Insul Class F Protection NOT Therm.Prot.
Eff 100% 80 Eff 75%   PF 75
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE Yes Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 38 LB Enclosure TENV Lubrication POLYREX EM
Nameplate 080904 Mounting C FACE Rotation REV
1HP LEESON 1740RPM 143TC TENV 3PH MOTOR 120760.00
Click Image to Enlarge
Picture is for quick reference only.
Manufacturer Part Number: 120760.00
Stock # 120760
Price: $365.00
Compare At: $849.00
