2HP LEESON 1800RPM 56C TENV 1PH MOTOR 117179.00

Catalog Number:  117179.00 - FREE Ground Shipping in USA
Model Number: C6C17NC99 A
Description:  2HP,1800RPM,56C,TENV,1PH,60HZ,BOAT HOIST
Ship Weight:  43 lbs.

LEESON/ELECTRA Single Phase Stainless Steel Boat Hoist Motors provide customized features that are needed to support the Boat Hoist Industry.

FEATURES:

  • Made in USA
  • Stainless Steel frame, capacitor case and conduit box cover
  • 15 Minute Duty Cycle
  • 5/8" Keyed output shaft
  • Baseless design
  • Drain Holes located at 6:00 position
  • TENV enclosure
  • Die Cast Aluminum endbells
  • Capacitor case located at 12:00
  • 115/230 Volt - 1.15 Service Factor
  • UL and CSA listed
Volts 115   Volts 208-230   Volts
FL Amps 24.8   FL Amps 12.4   FL Amps
SF Amps 26   SF Amps 13   SF Amps
RPM 1800   Hertz 60
HP 2   Duty 30 MINUTE   Type CN
KW 1.49   SF 1.15   Phase 1
Frame 56C   Design NO DESIGN CODE   KVA Code H
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class F   Eff(75%)     PF 71
Eff(100%) 73   CSA Y   Bearing OPE 6203
UL Y-(LEESON UL REC)   CE N   Bearing PE 6203
CC Number EXEMPT   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 43 LB   Enclosure TENV   Lubrication POLYREX EM
Nameplate 993500   Mounting ROUND   Rotation SELECTIVE CCW
Shaft Diam.     Cust Part No.     Packaging B
      Winding C634278   Carton Label INDIVIDUAL
      Group 3   Iris
Paint NO PAINT   Hazardous Location NONE   Test Card 01
2HP LEESON 1800RPM 56C TENV 1PH MOTOR 117179.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 117179.00
Stock # 117179
Price: $332.00
Compare At: $771.00
