5HP LEESON 3600RPM 56H ODP 230V 1PH MOTOR 116708.00

Catalog Number:  116708.00 - FREE Ground Shipping in USA
Model Number:  P6K34DB26A
Description:  5HP,3450RPM,56H,DP,230V,1PH,60HZ
Ship Weight:  45 lbs.

LEESON Pressure Washer ODP Motors: Specially suited for hot or cold pressure washer applications and other single phase installations requiring minimum starting and running amperages.

Features Include:

  • Made in USA
  • 5/8" Keyed output shaft
  • Durable rolled steel frame
  • Pressure Washer Duty
  • Manual Overload Protection
  • High service factor
  • Windings dipped in heavy duty varnish system
  • Capacitor start/capacitor run design for reduced amperage
  • High-quality double shielded ball bearings
  • Dynamically balanced rotors
  • Some 56 frame motors have a 56, 56H, 143T and 145T combination base with 12 mounting holes for flexible installation
  • Warranty: 12 months from the date of purchase or 18 months from the date of manufacture, whichever comes first
  • UL Recognized Component Listing and CSA approval.
Volts 230 Volts   Volts
F.L. Amps 20.8 F.L. Amps   F.L. Amps
S. F Amps None S. F Amps   S. F Amps
RPM 3600 Hertz 60
KW 3.70 Model # P6K34DB26A
Frame 56H Serv. Factor 1.0 Phase 1
Max Amb 40 Design L Code E
Insul Class F Protection MANUAL Therm.Prot. BEJ34DB
Eff 100% 82.5 Eff 75%   PF 95
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6205
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 45 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004001 Mounting RIGID Rotation SELECTIVE CCW
5HP LEESON 3600RPM 56H ODP 230V 1PH MOTOR 116708.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 116708.00
Stock # 116708
Price: $451.00
Compare At: $1,072.00
