1/3HP LEESON 3450RPM 56C TEFC 3PH MOTOR 116641

Catalog Number: 116641.00
Model Number: C6T34VK15
Description:  1/3HP,3450RPM,56C,TEFC,3PH,60HZ,WASHGUARD
Ship Weight: 22 lbs.

This LEESON motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

LEESON WASHGUARD WHITE EPOXY Three Phase Motors are designed for superior extended service in severe environments. Typical applications include food processing areas requiring frequent sanitation procedures using high pressure cleaning with concentrated caustic solutions, areas of high humidity and in chemical environments.

NOTE: This motor is totally enclosed non ventilated.

  • LEESON'S original moisture-shedding "duck" motor
  • USDA-approved white epoxy finish
  • Stainless steel shaft, conduit box cover, nameplate, fan guard
  • Special gaskets, slingers and seals
  • Four endshield drains
  • IRIS insulation system
  • Moisture-resistant interior components
  • Meets IP55 enclosure protection
  • Three phase motors are suitable for use on VFDs
  • 10:1 ratio for constant or variable torque at 1:0 SF
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 1.1 F.L. Amps .55 F.L. Amps 1/.5
S. F Amps 1.2 S. F Amps .6 S. F Amps 1.1/.55
RPM 3600 Hertz 60/50
HP 1/3 Duty CONTINUOUS TYPE TF
KW 0.25 Model # C6T34VK15 B
Frame 56C Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code L
Insul Class F Protection NOT Therm.Prot.
Eff 100% 0 Eff 75%   PF 0
UL Yes CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 22 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 080278 Mounting C FACE Rotation REV
1/3HP LEESON 3450RPM 56C TEFC 3PH MOTOR 116641
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 116641.00
Stock # 116641
Price: $297.00
Compare At: $790.00
