1/3HP LEESON 1725RPM 56C 1PH HI-TORQUE MOTOR 116485.00

Catalog Number:  116485.00 - Made in USA
Model Number:  M6C17FK81E
Description:  1/3HP,1725RPM,56C,TEFC,HI-TORQUE,1PH,60HZ
Ship Weight:  26 lbs.

This Leeson motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

APPLICATIONS: Designed specifically for severe "farm duty" environments and applications, but work very well in standard environments such as Air compressors, pumps and other single phase machinery.

Mechanical Features:

  • Made in USA
  • Steel frame
  • 5/8" shaft output diameter
  • Gasketed capacitor housing and conduit boxes provide protection in all environments.
  • Double sealed ball bearings pre-lubricated with Exxon POLYREX EM grease having operating temperature range of -20*F to +350*F and special formulation to provide extra bearing protection.
  • Rubber boot over manual protector reset button provides weather protection.

Electrical Features:

  • Low temperature manual overload protector protects against extreme overload.
  • Class "F" copper windings and varnish.
  • Capacitor start provides high starting torque with normal starting current.
Volts 115 Volts 208-230 Volts
F.L. Amps 6.4 F.L. Amps 3.2 F.L. Amps
S. F Amps 6.6 S. F Amps 3.3 S. F Amps
RPM 1800 Hertz 60
KW .246 Model # M6C17FK81E
Frame 56C Serv. Factor 1.15 Phase 1
Max Amb 40 Design N Code M
Insul Class B Protection MANUAL Therm.Prot. CED3769
Eff 100% 62 Eff 75%   PF 55
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 26 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 993500 Mounting RIGID C Rotation SELECTIVE CCW
1/3HP LEESON 1725RPM 56C 1PH HI-TORQUE MOTOR 116485.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 116485.00
Stock # 116485
Price: $175.00
Compare At: $695.00
