1/2HP LEESON 1725RPM 56C TENV 3PH MOTOR 116467
| Catalog Number: | 116467.00 |
| Model Number: | C6T17VK30 |
| Description: | 1/2HP,1725RPM,56C,TENV,3PH,BRAKE,WASHGUARD |
| Brake Rating Ft-Lbs: | 3 |
| Ship Weight: | 34 lbs. |
APPLICATIONS: Fail-safe positive, stop and hold brakemotors designed for superior extended service in severe enviroments. Brakes are spring set. Load stopped automatically when power is turned off. LEESON brakemotors feature a power off manual release for convenience, and for use in case of a power failure. The manual release resets automatically. The brake coil leads are brought into the conduit box of the motor for easy connection and may be connected to operate when power to the motor is shut off, or to be actuated independent of power to the motor. Three phase motors have brake coils rated for 230/460VAC, 60Hz.
FEATURES:
- Made in U.S.A.
- Steel frame design
- TENV enclosure, C-Face with Base
- 1.15 Service Factor
- 3 ft-lbs Brake rating
| Volts | 208-230 | Volts | 460 | Volts | |
| F.L. Amps | 2.0-1.8 | F.L. Amps | .9 | F.L. Amps | |
| S. F Amps | 2 | S. F Amps | 1 | S. F Amps | |
| RPM | 1800 | Hertz | 60 | ||
| HP | 1/2 | Duty | CONTINUOUS | TYPE | TN |
| KW | 0.37 | ||||
| Frame | 56C | Serv. Factor | 1.15 | Phase | 3 |
| Max Amb | 40 | Design | B | Code | L |
| Insul Class | F | Protection | NOT | Therm.Prot. | |
| Eff 100% | 78.5 | Eff 75% | PF | 67 | |
| UL | Yes | CSA | Yes | Bearing OPE | 6203 |
| CC Number | NONE | CE | Yes | Bearing PE | 6205 |
| Load Type | Inverter Type | Speed Range | NONE | ||
| Motor Wt. | 34 LB | Enclosure | TENV | Lubrication | POLYREX EM |
| Nameplate | 080904 | Mounting | ROUND | Rotation | REV |
| Assembly | NONE | Shaft Dia. | 5/8 IN | Ext. Diag. | 005010.15 |
