2HP LEESON 1725RPM 56C DP 3PH MOTOR 115553

LEESON 115553.00 has been superseded by E116742.00

Catalog Number:  115553.00
Description:  2HP,1725RPM,56C,DP,3PH,60HZ
Ship Weight:  34 lbs.

DP Models: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

Features Include:

  • Durable rolled steel frame
  • High-quality ball bearings
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA approval.
  • Warranty – 12 months from date of first use or 18 months from date of manufacture, whichever comes first.
Volts 208-230 Volts 460 Volts
F.L. Amps 6.2 F.L. Amps 3.1 F.L. Amps
S. F Amps 6.8 S. F Amps 3.4 S. F Amps
RPM 1800 Hertz 60
KW 1.492 Model Number C6T17DC77 A
Frame F56C Serv. Factor 1.15 Phase 3
Max Amb 40 Design C Code J
Insul Class B Protection NOT Therm.Prot.
Eff 100% 78.5 Eff 75%   PF 77
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 34 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004002 Mounting C FACE Rotation REV
2HP LEESON 1725RPM 56C DP 3PH MOTOR 115553
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 115553.00
Stock # 115553
