2HP LEESON 3450RPM 56C DP 3PH MOTOR 114218.00

LEESON 114218.00 as been superseded by E114218.00

Catalog Number:  114218.00 Made in USA
Model Number:  C6T34DK8B
Description:  2HP,3450RPM,56C,DP,3PH,60HZ
Ship Weight:  37 lbs.

This Leeson Motor is subject to availability.

APPLICATIONS: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

FEATURES:

  • Made in USA
  • Durable rolled steel frame
  • 5/8" shaft output diameter
  • High-quality ball bearings
  • Inverter-rated
  • Shielded ball bearings for direct coupled applications
  • Continuous duty
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA certified
  • Standard efficiency with 1 year warranty
Volts 208-230 Volts 460 Volts
F.L. Amps 5.8-5.6 F.L. Amps 2.8 F.L. Amps
S. F Amps 6.4-6.2 S. F Amps 3.1 S. F Amps
RPM 3600 Hertz 60
HP 2 Duty CONTINUOUS TYPE TD
KW 1.492 Model Number C6T34DK8 B
Frame 56C Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code L
Insul Class B Protection NOT Therm.Prot.
Eff 100% 82.5 Eff 75%   PF 84
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 37 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004002 Mounting RIGID C Rotation REV
2HP LEESON 3450RPM 56C DP 3PH MOTOR 114218.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 114218.00
Stock # 114218
