2HP LEESON 3450RPM 56J TEFC 3PH MOTOR 114205.00
LEESON 114205.00 has been superseded by 119455.00
| Catalog Number: | 114205.00 |
| Spec Number: | C6T34FC40 E |
| Description: | 2HP,3450RPM,56J,TEFC,3PH,60HZ |
| Ship Weight: | 34 lbs. |
| Volts | 208-230 | Volts | 460 | Volts | |
| F.L. Amps | 5.8-5.6 | F.L. Amps | 2.8 | F.L. Amps | |
| S. F Amps | 6.4-6.2 | S. F Amps | 3.1 | S. F Amps | |
| RPM | 3600 | Hertz | 60 | ||
| HP | 2 | Duty | CONTINUOUS | TYPE | TF |
| KW | 1.49 | Model # | C6T34FC40E | ||
| Frame | 56J | Serv. Factor | 1.15 | Phase | 3 |
| Max Amb | 40 | Design | B | Code | L |
| Insul Class | B | Protection | NOT | Therm.Prot. | |
| Eff 100% | 82.5 | Eff 75% | PF | 84 | |
| UL | Y-(LEESON UL REC) | CSA | Yes | Bearing OPE | 6203 |
| CC Number | EXEMPT | CE | No | Bearing PE | 6203 |
| Load Type | Inverter Type | Speed Range | NONE | ||
| Motor Wt. | 34 LB | Enclosure | TEFC | Lubrication | POLYREX EM |
| Nameplate | 993500 | Mounting | ROUND | Rotation | REV |
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 114205.00
Stock # 114205
