3/4HP LEESON 2850RPM 56 IP22 1PH MOTOR 113902.00
|Catalog Number:||113902.00 Made in USA|
|Ship Weight:||30 lbs.|
This Leeson motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.
DP Models: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.
General Specifications: 50 Hz single phase designs produce full rated HP on 50Hz power supply. Designed for general purpose applications.
Electrical Features: High efficiency energy saving designs. Centrifugal switch specifically designed for 50 Hz service. Conduit box with leads. Torque at rated HP on 50 Hz power supply is 20% greater than the running torque of a 60 Hz motor. All 180 and 210 frame Rolled Steel motors have Class F Insulation.
- Made in USA
- 5/8" shaft output diameter
- Durable rolled steel frame
- High-quality ball bearings
- Easy-to-read nameplate
- UL Recognized Component Listing and CSA approval.
- Warranty – 12 months from date of first use or 18 months from date of manufacture, whichever comes first.
|F.L. Amps||11.2||F.L. Amps||5.6||F.L. Amps|
|S. F Amps||12.6||S. F Amps||6.3||S. F Amps|
|Eff 100%||Eff 75%||PF|
|CC Number||CE||Yes||Bearing PE||6203|
|Load Type||Inverter Type||Speed Range||NONE|
|Motor Wt.||30 LB||Enclosure||IP22||Lubrication||POLYREX EM|
