1.5HP LEESON 3600RPM 56HC TENV 3PH MOTOR 113591.00

Catalog Number:  113591.00 - FREE Ground Shipping in USA
Model Number: C6T34VK5
Description:  1.5HP,3450RPM,56HC,TENV,3PH,60HZ,WASHGUARD
Ship Weight: 45 lbs.

LEESON Three Phase White Duck Washguard Epoxy Motor is designed for enhanced performance in wet, humid areas. Designed to meet the demanding washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

  • Made in the USA
  • NEMA Premium efficiency rating with a three year warranty
  • The original moisture-shedding "duck" motor
  • Durable rolled steel frame
  • C-Face mounting provisions with rigid base
  • Combination 56H base has mounting holes for 56 and 143-5T
  • USDA-approved, high-gloss, white epoxy finish
  • 5/8" Keyed output shaft
  • 303 stainless-steel shaft and moisture-resistant shaft system
  • Frame, base, endshields, rotor, and interior components are protected by enamel and polyester compounds
  • High temperature, moisture resistant IRIS® insulation system
  • Cast, oversized conduit box with tough, high-temperature nitrile gaskets and stainless-steel cover and hardware
  • Excellent for applications requiring a motor that is "tropicalized"
  • Double-sealed, oversized bearings
  • Stainless-steel or white polypropylene fan guard on all Washguard frames.
  • Stainless-steel, “full-fact” nameplate
  • Four condensate drains in each endshield
  • Meets IP55 enclosure protection
Volts 208-230 Volts 460 Volts
F.L. Amps 4.2-3.8 F.L. Amps 1.9 F.L. Amps
S. F Amps 4.6-4.2 S. F Amps 2.1 S. F Amps
RPM 3600 Hertz 60
HP 1 1/2 Duty CONTINUOUS TYPE TN
KW 1.12 Model # C6T34VK5 H
Frame 56HC Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code L
Insul Class F Protection NOT Therm.Prot.
Eff 100% 84 Eff 75%   PF 88
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE Yes Bearing PE 6205
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 47 LB Enclosure TENV Lubrication POLYREX EM
Nameplate 080904 Mounting RIGID C Rotation REV
1.5HP LEESON 3600RPM 56HC TENV 3PH MOTOR 113591.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 113591.00
Stock # 113591
Price: $399.00
Compare At: $1,053.00
