3HP LEESON 3450RPM 56C DP 230V 1PH MOTOR 113334.00

3HP LEESON 3450RPM 56C DP 230V 1PH MOTOR 113334.00

Picture is for reference only.

Part Number:

113334.00

Model/Spec Number:

P6C34DC50D

Manufacturer:

Leeson Obsolete
113334.00 LEESON 3HP Single Phase Electric Motor for use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

36 lbs

Dimensions:

13 x 24 x 13 inches

HS Code:

8501.40.0000

Technical Details

Application:

General Purpose

Output HP:

3

Output KW:

2.2

Output RPM:

3450

Frame NEMA:

56C

Mount NEMA:

C-Face No Base

Enclosure NEMA:

DP

Voltage:

230

Frequency (Hz):

60

Efficiency:

76.0

Motor Drawing

Connection Diagram

Volts 230 Volts   Volts
F.L. Amps 15 F.L. Amps   F.L. Amps
S. F Amps   S. F Amps   S. F Amps
RPM 3600 Hertz 60
HP 3 Duty CONTINUOUS TYPE CD
KW 2.238 Model # P6C34DC50D
Frame 56C Serv. Factor 1.0 Phase 1
Max Amb 40 Design L Code G
Insul Class F Protection AUTOMATIC Therm.Prot. CEJ31CV
Eff 100% 76 Eff 75%   PF 90
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 39 LB Enclosure DP Lubrication POLYREX EM
Nameplate 080033 Mounting C FACE Rotation SELECTIVE CCW
