2HP LEESON 1725RPM 56HC DP 1PH MOTOR 113281.00

Catalog Number:  113281.00
Model Number:  P6K17DK12G
Description:  2HP,1725RPM,56HC,DP,1PH,60HZ
Ship Weight:  48 lbs.

APPLICATIONS: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

FEATURES:

  • Durable rolled steel frame
  • 5/8" shaft output diameter
  • Manual overload protection
  • High-quality ball bearings
  • Capacitor start/capacitor run design for reduced amperage
  • Easy-to-read nameplate
  • Some 56 frame motors have a 56, 56H, 143T and 145T combination base with 12 mounting holes for flexible installation
  • UL Recognized Component Listing and CSA approval.
  • 1 year warranty
Volts 115 Volts 208-230 Volts
F.L. Amps 17.2 F.L. Amps 8.6 F.L. Amps
S. F Amps 19.4 S. F Amps 9.7 S. F Amps
RPM 1800 Hertz 60
HP 2 Duty CONTINUOUS TYPE KD
KW 1.49 Model # P6K17DK12G
Frame 56HC Serv. Factor 1.15 Phase 1
Max Amb 40 Design L Code J
Insul Class B Protection MANUAL Therm.Prot. BEJ46DA
Eff 100% 79 Eff 75%   PF 95
UL No CSA No Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 48 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004004 Mounting RIGID C Rotation SELECTIVE CCW
2HP LEESON 1725RPM 56HC DP 1PH MOTOR 113281.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 113281.00
Stock # 113281
Price: $368.00
Compare At: $893.00
