1HP LEESON 1725RPM 56H DP 3PH MOTOR 111960

LEESON Catalog Number:  111960.00
Description:  1/0.44HP,1725/1140RPM,56H,DP,3PH,60/60HZ
Ship Weight:  43 lbs.

LEESON Single Phase Variable torque, two-speed motors are Industrial quality, resilient (cradle) mounted, are suited for belted or fan on shaft applications. They are self ventilated, and may be mounted within or outside of the driven fan's air stream.

Resilient mounted for quiet operation, and lubricated with high temperature Exxon POLYREX® EM lubricant.

3/4 HP and larger single phase are capacitor start motors; smaller single phase are split phase start.

NOTES:

  • Combination 56H base motors have mounting holes for NEMA 56 and NEMA 143-5T and a standard NEMA 56 shaft.
Volts 208-230 Volts   Volts 208-230
F.L. Amps 4 F.L. Amps   F.L. Amps 2.4
S. F Amps   S. F Amps   S. F Amps
RPM 1800 Hertz 60/60
HP 1 Duty CONTINUOUS TYPE TD
KW .75 Model # C6T46DR5D
Frame 56H Serv. Factor 1.0 Phase 3
Max Amb 40 Design NO DESIGN CODE Code M
Insul Class B Protection NOT Therm.Prot.
Eff 100%   Eff 75%   PF
UL Yes CSA Yes Bearing OPE 6203
CC Number NONE CE No Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 43 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004001 Mounting RESIL Rotation REV
1HP LEESON 1725RPM 56H DP 3PH MOTOR 111960
Click Image to Enlarge
Manufacturer Part Number: 111960.00
Stock # 111960
Price: $508.00
Compare At: $1,281.00
