3/4HP LEESON 1725/1140RPM 56H DP 3PH MOTOR 111959

LEESON Catalog Number:  111959.00
Description:  3/4-1/3HP,1725/1140RPM,56H,DP,3PH,60/60HZ
Ship Weight:  39 lbs.

This Leeson motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

LEESON Single Phase Variable torque, two-speed motors are Industrial quality, resilient (cradle) mounted, are suited for belted or fan on shaft applications. They are self ventilated, and may be mounted within or outside of the driven fan's air stream.

Resilient mounted for quiet operation, and lubricated with high temperature Exxon POLYREX® EM lubricant.

NOTES:

  • Combination 56H base motors have mounting holes for NEMA 56 and NEMA 143-5T and a standard NEMA 56 shaft.
Volts 460 Volts   Volts 460
F.L. Amps 1.4 F.L. Amps   F.L. Amps .8
S. F Amps None S. F Amps   S. F Amps
RPM 1800 Hertz 60/60
HP .75 Duty CONTINUOUS TYPE TD
KW 0.56 Model # C6T46DR4D
Frame 56H Serv. Factor 1.0 Phase 3
Max Amb 40 Design NO DESIGN CODE Code L
Insul Class B Protection NOT Therm.Prot.
Eff 100%   Eff 75%   PF
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 39 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004001 Mounting RESIL Rotation REV
3/4HP LEESON 1725/1140RPM 56H DP 3PH MOTOR 111959
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 111959.00
Stock # 111959
Price: $447.00
Compare At: $1,128.00
Quantity:
