1HP LEESON 1725RPM 56C DP 3PH GENERAL PURPOSE MOTOR 110901.00

1HP LEESON 1725RPM 56C DP 3PH GENERAL PURPOSE MOTOR 110901.00

Picture is for reference only.

Part Number:

110901.00

Model/Spec Number:

C6T17DK3

Manufacturer:

Leeson Obsolete
LEESON 110901.00 1HP Three Phase DP Motor is designed for use where water and dust exposure is moderate.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

20 lbs

Dimensions:

12 x 20 x 12 inches

HS Code:

8501.52.4000

Technical Details

Brand:

Leeson

Application:

General Purpose

Output HP:

1

Output KW:

0.75

Output RPM:

1725

Frame Size NEMA:

56C

Mount NEMA:

C Face With Base

Enclosure NEMA:

DP

Voltage:

208-230/460

Frequency (Hz):

60

Connection Diagram

Volts 208-230 Volts 460 Volts
F.L. Amps 4.2 F.L. Amps 2.1 F.L. Amps
S. F Amps 4.5 S. F Amps 2.25 S. F Amps
RPM 1800 Hertz 60
HP 1 Duty CONTINUOUS TYPE TD
KW .75 Model Number C6T17DK3 E
Frame D56C Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code K
Insul Class B Protection NOT Therm.Prot.
Eff 100% 78.5 Eff 75%   PF 58
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 24.4 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004002 Mounting RIGID C Rotation REV
