1.5HP LEESON 3450RPM 56H DP 1PH MOTOR 110479.00

Catalog Number:  110479.00
Model Number:  A6C34DR7E
Description:  1.5HP,3450RPM,56H,DP,1PH,60HZ
Ship Weight:  33 lbs.

APPLICATIONS: Industrial quality, resilient (cradle) mounted, capacitor start-type, ball bearing motors for fan and blower service. Moderate starting torque electrical design to reduce stress on fan blades during start-up. Capacitor-type design has higher energy efficiency rating than split phase, single phase fan and blower motors. Suitable for belt-driven fans or fan-or-shaft applications. Self-ventilated design, may be mounted outside of the fan's airflow.

FEATURES:

  • Made in USA
  • 5/8" shaft output diameter
  • Drip-proof and totally enclosed designs
  • Industrial quality, resilient (cradle) mounted
  • Capacitor start-type
  • Ball bearing designs
  • Moderate starting torque to reduce machinery stresses
  • Suitable for belt-driven fans or fan-on-shaft applications
Volts 115 Volts 208-230 Volts
F.L. Amps 16.4 F.L. Amps 8.6-8.2 F.L. Amps
S. F Amps 18 S. F Amps 9.8-9 S. F Amps
RPM 3600 Hertz 60
HP 1.5 Duty CONTINUOUS TYPE CD
KW 1.119 Model # A6C34DR7E
Frame 56H Serv. Factor 1.15 Phase 1
Max Amb 40 Design L Code G
Insul Class B Protection AUTOMATIC Therm.Prot. CEJ38CV
Eff 100% 74 Eff 75%   PF 80
UL No CSA No Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 33 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004004 Mounting RESIL Rotation SELECTIVE CCW
1.5HP LEESON 3450RPM 56H DP 1PH MOTOR 110479.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 110479.00
Stock # 110479
Price: $319.00
Compare At: $804.00
