1.5HP LEESON 3450RPM 56C DP 3PH MOTOR 110437.00

LEESON 110437.00 has been superseded by E110437.00

Catalog Number:  110437.00
Model Number:  C6T34DC12E
Description:  1.5HP,3450RPM,56C,DP,3PH,60HZ
Ship Weight:  30 lbs.
Volts 208-230 Volts 460 Volts
F.L. Amps 4.4-4.2 F.L. Amps 2.1 F.L. Amps
S. F Amps 5-4.8 S. F Amps 2.4 S. F Amps
RPM 3600 Hertz 60
HP 1.5 Duty CONTINUOUS TYPE TD
KW 1.12 Model Number C6T34DC12 E
Frame 56C Serv. Factor 1.15 Phase 3
Max Amb 40 Design B Code K
Insul Class B Protection NOT Therm.Prot.
Eff 100% 81.5 Eff 75%   PF 84
UL Yes CSA Yes Bearing OPE 6203
CC Number   CE No Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 30 LB Enclosure DP Lubrication POLYREX EM
Nameplate 993500 Mounting C FACE Rotation REV
1.5HP LEESON 3450RPM 56C DP 3PH MOTOR 110437.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 110437.00
Stock # 110437
