2HP LEESON 3450RPM 56 DP 115/208-230V 1PH MOTOR 110362.00

Picture is for reference only.

Part Number:

110362.00

Model/Spec Number:

P6C34DB21E

Manufacturer:

Leeson Obsolete

110362.00 LEESON 2HP Single Phase Electric Motor for use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

41 lbs

Dimensions:

11 x 18 x 11 inches

HS Code:

8501.40.0000

Technical Details

Specifications

Application:	General Purpose
Output HP:	2
Output KW:	1.5
Output RPM:	3450
Frame NEMA:	56
Mount NEMA:	Base Mount
Enclosure NEMA:	DP
Voltage:	115/208-230
Frequency (Hz):	60
Efficiency:	77.0

Documentation

Motor Drawing

Connection Diagram

Additional Information

Volts	115	Volts	208-230	Volts
F.L. Amps	20	F.L. Amps	11-10	F.L. Amps
S. F Amps	23.6	S. F Amps	12.8-11.8	S. F Amps
RPM	3600	Hertz	60
HP	2	Duty	CONTINUOUS	TYPE	CD
KW	1.492	Model #	P6C34DB21E
Frame	56	Serv. Factor	1.15	Phase	1
Max Amb	40	Design	L	Code	J
Insul Class	B	Protection	MANUAL	Therm.Prot.	BEJ72DA
Eff 100%	77	Eff 75%		PF	82
UL	No	CSA	Yes	Bearing OPE	6203
CC Number		CE	No	Bearing PE	6203
Load Type		Inverter Type	NONE	Speed Range	NONE
Motor Wt.	41 LB	Enclosure	DP	Lubrication	POLYREX EM
Nameplate	004004	Mounting	RIGID	Rotation	SELECTIVE CCW
Assembly	NONE	Shaft Dia.	5/8 IN	Ext. Diag.	005067.01
Cust Part No		Outline	028599-750B	Ext. Diag2
