3/4HP LEESON 1725RPM 56C TEFC 1PH MOTOR 110308.00

Catalog Number:  110308.00 Made in USA
Model Number:  A6C17FC8L
Description:  3/4HP,1725RPM,56C,TEFC,1PH,60HZ
Ship Weight:  31 lbs.

APPLICATIONS: For use where exposure is limited to splashes of water, dust and/or where mild corrosives exist. Ideally, suited for use on pumps, compressors, blowers, fans, conveyors, machine tools and other direct or belt-driven applications. Not for continuous outdoor use without proper shielding or for use with harsh chemicals.


  • Made in USA
  • Durable rolled steel frame
  • 5/8" shaft output diameter
  • Automatic overload protection
  • High-quality ball bearings
  • Capacitor start
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA approval
  • 1 year warranty
Volts 115 Volts 208-230 Volts
F.L. Amps 10.8 F.L. Amps 5.4 F.L. Amps
S. F Amps 11.4 S. F Amps 5.7 S. F Amps
RPM 1800 Hertz 60
KW 0.56 Model Number A6C17FC8L
Frame 56C Serv. Factor 1.15 Phase 1
Max Amb 40 Design N Code L
Insul Class B Protection AUTOMATIC Therm.Prot. CEJ53CV
Eff 100% 70 Eff 75%   PF 64
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 31 LB Enclosure TEFC Lubrication POLYREX EM
Nameplate 993500 Mounting ROUND Rotation SELECTIVE CCW
3/4HP LEESON 1725RPM 56C TEFC 1PH MOTOR 110308.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 110308.00
Stock # 110308
Price: $266.00
Compare At: $671.00
