1HP LEESON 1725RPM 56 DP 115/208-230V 1PH MOTOR 110167.00

Picture is for reference only.

Part Number:

110167.00

Model/Spec Number:

M6C17DB7J

Manufacturer:

Leeson Obsolete

110167.00 LEESON 1HP Single Phase Electric Motor for use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

33 lbs

Dimensions:

12 x 20 x 12 inches

HS Code:

8501.40.0000

Technical Details

Specifications

Application:	General Purpose
Output HP:	1
Output KW:	0.75
Output RPM:	1725
Frame NEMA:	56
Mount NEMA:	Base Mount
Enclosure NEMA:	DP
Enclosure IEC:	IP22
Voltage:	115/208-230
Frequency (Hz):	60

Documentation

Motor Drawing REF DASH-600

Connection Diagram

Additional Information

Volts	115	Volts	208-230	Volts
F.L. Amps	12.8	F.L. Amps	6.4	F.L. Amps
S. F Amps	13.6	S. F Amps	6.8	S. F Amps
RPM	1800	Hertz	60
HP	1	Duty	CONTINUOUS	TYPE	CD
KW	.75	Model #	M6C17DB7J
Frame	E56	Serv. Factor	1.15	Phase	1
Max Amb	40	Design	N	Code	K
Insul Class	B	Protection	MANUAL	Therm.Prot.	CEJ50CA
Eff 100%	75	Eff 75%		PF	68
UL	Yes	CSA	Yes	Bearing OPE	0
CC Number		CE	No	Bearing PE	0
Load Type		Inverter Type	NONE	Speed Range	NONE
Motor Wt.	33 LB	Enclosure	DP	Lubrication	STANDARD
Nameplate	004004	Mounting	RIGID	Rotation	SELECTIVE CCW
